SSL MadiXtreme 64-channel PCIe-MADI card

MadiXtreme is a multichannel PCIe audio card for Mac and PC from Solid State Logic, that featuring PCIe-Core Audio Pipeline technology.

MadiXtreme takes full advantage of the high speeds and incredible bandwidth offered by the PCIe bus on modern computers.

With one optical MADI connector for 64 simultaneous I/Os, the MADI Xtreme 64 is the ideal interface for the SSL Alpha-Link MADI AX or SSL Alpha-Link MADI SX. MADI Xtreme 64 is also the perfect partner for MADI equipped consoles, live recording, installations and broadcast servers.

Features:

- PCIe half-length card, single-lane PCIe v1.1-3.0
- 1x MADI I/O (optical)
- Channel count: 56/64 Ch@44.1/48k, 28/32 Ch@88.2/96k, 14/16 - Ch@176.4/192k
- 1x Wordclock Connector (Software controlled as Input or Output)

Windows: (XP or Vista 32 Bit): ASIO 2, WDM, MME, GSIF2, DWave
Mac OS: OS X (10.4 or 10.5): Core Audio.

Minimum System Requirements:

Windows: Windows XP (SP2) or Vista (32-Bit) Intel or AMD Configuration with one free PCIe Slot

Mac OS: Mac OS X 10.4 (Tiger) or Mac OS X 10.5 (Leopard) G5 or Intel Mac with one free PCIe Slot

Note: PCIe (PCI Express) is not compatible with PCI or PCI-X
